U11163 Series Excitation Motor
Product Introduction
- Model Variants: Includes U11163-1M (120V) and U11163-03H (230V), both operating at 50/60Hz frequency.
- Performance: 21,000 RPM no-load speed, 12,000 RPM at maximum efficiency, ensuring high-speed operation.
- Load Capacity: Provides up to 5,000mN·m stall torque, delivering powerful and reliable performance.
Product Application
- Home Appliances: Food Blender
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Model | Voltage | Load | At Maximum Efficiency | Stall | ||||||||
| Scope of work (V) |
Rated (V) |
Speed (r/min) |
Current (A) |
Speed (r/min) |
Current (A) |
Torque (mN.m) |
Torque (g.cm) |
Output (W) |
Torque (mN.m) |
Torque (g.cm) |
Current (A) |
|
| U11163-1M | 104.4~127 VAC 50/60Hz | 120V AC | 21000 | 7 | 12000 | 20 | 1280 | 13056 | 1600 | 5000 | 51000 | 34.5 |
| U11163-o3H | 210~230 VAC 50/60Hz | 230V AC | 21000 | 3.5 | 12000 | 10 | 1280 | 13056 | 1600 | 5000 | 51000 | 17 |
Mechanical Dimension: mm
Performance Curves
