Micro DC Brush Motor
WARM REMINDER
You can filter products according to your needs. This screening system is for reference only, if you do not match the product you want, you can contact us.
Naming Convention
The LEILI micro DC brush motor offers high efficiency and compact design, perfect for small-scale applications. With a voltage range of 12V to 240V, it delivers speeds up to 15,000 RPM and a torque of 1.12-49 N·m. Perfect for robotics, toys, and portable devices, it guarantees dependable performance and an extended lifespan.
Product Introduction
- Efficient Performance: Operates at 115V with ≤0.2A input current, ensuring energy-efficient functionality.
- Stable Speed: Delivers a no-load speed of 32±10%, maintaining reliable rotational consistency.
- Compact Power: Provides ≤6.6W input power, ideal for precision-driven micro DC applications.
Product Application
- Automobile tail hook
Product Introduction
- Efficient Performance: Operates at 120V with ≤0.5A input, ensuring reliable and stable power efficiency.
- High-Speed Operation: Perfect for precision-driven applications, it has a no-load speed of 11200±10%.
- Low Power Consumption: Consumes ≤6.6W, making it an energy-efficient choice for various compact devices.
Product Application
- Refrigerator
Product Introduction
- Model: FS-5710SH
- Wide Voltage Range: Operates between 8V-16.5V, with a rated voltage of 12V for versatile applications.
- High Performance: Delivers 4500 RPM at no load, 3800 RPM max with 50 mN·m torque output.
- Powerful & Efficient: Generates 19W output power, with a stall torque of 234 mN·m for demanding tasks.
Product Application
- Automobile: Automobile throttle valve
Product Introduction
- Model: RF-500TB
- Versatile Voltage Range: Operates efficiently from 1.5V to 9.0V, with a nominal 5V rating.
- Smooth Performance: Achieves 3100 r/min no-load speed with a low current draw of 0.026A.
- Efficient Torque Output: Delivers 1.23 mN·m torque at 2540 r/min with 0.12A maximum efficiency current.
Product Application
- Industry: Audiovisual equipment
Product Introduction
- RS-5412SA 08130: Operates at 50-160V, 5850 RPM unloaded, 4550 RPM at max efficiency, 17.85 mN·m torque.
- RS-5412SA 08256: Runs on 50-250V, 5850 RPM unloaded, 4710 RPM at max efficiency, 26.55 mN·m torque.
- RS-5412SA 1095: High-speed motor, reaching 15000 RPM unloaded, ideal for precision applications requiring stable performance.
Product Application
- Appliance: Vacuum cleaner
Product Introduction
- Wide Voltage Range: RS-548SH operates from 6.5V to 16V, delivering stable performance across various applications.
- Efficient Performance: Runs at 6100 RPM unloaded, 4764 RPM at max efficiency, with 35 mN·m torque output.
- Reliable Power: Provides 17.476W output, handling up to 160 mN·m stall torque for demanding applications.
Product Application
- Automobile: Automobile throttle valve
