BLP43-4XX Electric Water Pump (adjustable High Head)
Product Introduction
- Adjustable High Head: Delivers up to 2400L/h flow with a maximum 17m head for versatile applications.
- Reliable & Durable: Operates in -40℃ to +85℃ conditions with a lifespan of ≥20000 hours under IP68 protection.
- Advanced Safety Protection: Equipped with over/under voltage, reverse connection, overcurrent, blocked rotation, and idling protection for safe operation.
Product Application
- Auto parts
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Model | Working Medium |
Ambient Temperature |
Medium Temperature |
Rated Voltage | Weight | Lifetime | Protection Level |
Protection Function |
| BLP43-4XX | Antifreeze | -40℃～ +85℃ | 40℃～ +85℃ (Limiting temperature +105℃) |
DC24V； Voltage range： DC18V ～ DC32V |
2.0kg （Base free） |
≥20000h | IP68 | Over/under voltage, blocked rotation,
Reverse connection, overcurrent, idling |
Performance Parameters
| Model | Rated Power | Rated Parameter | Inlet and Outlet Size |
| BLP43-4XX | 240W | Q=2400L/h , H=17m | Ø38mm/Ø25mm |
Mechanical Dimension: mm
