BLP43-3XX Electric Water Pump (large Flow)
Product Introduction
- Large Flow Capacity: Provides up to 6000L/h flow with a maximum head of 8m for efficient performance.
- Reliable & Long-Lasting: Operates from -40℃ to +85℃ with a lifespan of ≥ 20000 hours under IP68 protection.
- Comprehensive Safety Features: Equipped with over/under voltage, reverse connection, overcurrent, blocked rotation, and idling protection.
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Model | Working Medium |
Ambient Temperature |
Medium Temperature |
Rated Voltage | Weight | Lifetime | Protection Level |
Protection Function |
| BLP93-3XX | Antifreeze | -40℃～ +85℃ | 40℃～ +85℃ (Limiting temperature +105℃) |
DC24V； Voltage range： DC18V ～ DC32V |
2.0kg （Base free） |
≥ 20000h | IP68 | Over/under voltage, blocked rotation,
Reverse connection, overcurrent, idling |
Performance Parameters
| Model | Rated Power | Rated Parameter | Inlet and Outlet Size |
| BLP43-3XX | 250W | Q=6000L/h , H=8m | Ø38mm |
| 200W | Q=6000L/h , H=6m | ||
| 130W | Q=5000L/h , H=5m |
