BPX401/402 AC Synchronous Drain Pump
Product Introduction
- Motor Specifications: Copper or aluminum wire, 40mm stator, 110-240V voltage, 50/60Hz frequency, Class F insulation.
- Performance Characteristics: 38L/min flow rate, 1m lift, 40-80W power, 3000-3600 r/min speed, efficient drainage.
- Electrical Properties: 1-1.4A current, 102-187V starting voltage, ensuring stable and reliable operation.
Product Application
- Appliances: dishwasher, washing machine, humidifier, foot bath
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Model | Wire | Stator(mm) | Rated Voltage (VAC) |
Rated Frequency (Hz) |
Power (W) |
Current (A) |
Starting Voltage (V) |
Lift (m) |
Flow Rate (L/min) |
RPM (r/min) |
Insulation Class |
| BPX401-x | Cu | 40 | 110-120 | 60 | 80 | 1.4 | 102 | 1 | 38 | 3600 | F |
| BPX401-xL | Al | 110-120 | 60 | 80 | 1.4 | 102 | 1 | 38 | 3600 | ||
| BPX402-x | Cu | 220-240 | 50 | 40 | 1 | 187 | 1 | 38 | 3000 | ||
| BPX402-xL | Al | 220-240 | 50 | 40 | 1 | 187 | 1 | 38 | 3000 | ||
| BPX402-x | Cu | 220 | 60 | 80 | 1.4 | 187 | 1 | 38 | 3600 | ||
| BPX402-xL | Al | -220 | 60 | 80 | 1.4 | 187 | 1 | 38 | 3600 |
Mechanical Dimension: mm
