89SWS2-1 Plastic Brushless DC Motor
Product Introduction
- DC brushless motor 89SWS2-1
- Offers 900 RPM rated speed, 318mN·m torque, and ≤38 dB noise at 30cm.
- Operates at DC310V with 30W output power and E-grade (120) insulation for durability.
Product Application
- Air conditioner
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Number of Poles | DC Resistance Environment Temperature 25℃ | D-axis Inductance (mH) | D-axis Inductance (mH) | Back Potential Coefficient (V•s/rad) | Rated torque (318mN•m) | Insulation Class | |||||
| Rated Current (A) | Rated Voltage (V) | Rated Speed (r/min) | Output Power (W) | Noise dB(A) | Input Power (W) | ||||||
| 10P | DC310 | 139(1±9%) | 143(1±9%) | 0.156(1±5%) | 0.146±0.007 | DC310 | 900±5 | 30 | <38(30cm) | ≤ 45 | 120 Grade (E) |
Mechanical Dimensions: mm
