50SM25-1 Permanent Magnet Synchronous Motor
Product Introduction
- Model:50SM25
- Wide voltage range supports 12v-220v, 50/60hz, with speeds up to 1 rpm and ≥1.41 kgf·cm torque.
- Efficient operation consumes ≤3w power, maintains ≤60k temperature rise, and operates with ≤50a noise level.
Product Application
- Appliances: Air conditioning
- Industry: Valve control, timer
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Model | Rated Voltage | Freq | RPM | Current | Power | Output Torque | Starting Voltage | Temp | Noise | Insulation Level |
| （V） | (Hz) | (RPM) | （mA) | (W) | (kgf,cm) | （V） | (K) | (A) | ||
| 50SM25-1 | 12 | 50/60 | 0.033 | ≤300 | ≤3 | ≥1.41 | ≤9 | ≤60 | ≤50 | A |
| 24 | 50/60 | 0.033 | ≤240 | ≤3 | ≥1.41 | ≤19 | ≤60 | ≤50 | ||
| 120 | 60 | 0.028 | ≤60 | ≤3 | ≥0.19 | ≤90 | ≤60 | ≤40 | ||
| 120 | 60 | 0.033 | ≤60 | ≤3 | ≥1.41 | ≤90 | ≤60 | ≤40 | ||
| 120 | 60 | 1 | ≤60 | ≤3 | ≥0.5 | ≤90 | ≤60 | ≤40 | ||
| 220 | 60 | 0.028 | ≤30 | ≤3 | ≥0.19 | ≤180 | ≤60 | ≤40 | ||
| 220 | 50/60 | 0.033 | ≤30 | ≤3 | ≥1.41 | ≤180 | ≤60 | ≤40 | ||
| 220 | 50/60 | 1 | ≤30 | ≤3 | ≥0.19 | ≤180 | ≤60 | ≤40 |
Mechanical Dimensions: mm
