32ZYJ1-1 Sweeping Machine Side Brush Motor
Product Introduction
- Performance: 12V DC, 1:22.15 reduction ratio, 320±30 RPM no-load speed, ensuring efficient and smooth operation.
- Load Capacity: Gridlock torque ≥245mN·m, locked-rotor current ≤1.7A, providing stable and reliable performance.
- Noise Control: Operates at ≤50dB(A), ensuring quiet functionality for sweeping machine side brush applications.
Product Application
- Robot vacuum cleaner
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Voltage (DC.V) | Reduction Ratio | No-load Current (A) | No-load Speed(r/min) | Locked-rotor Current (A) | Gridlock Torque (mN.m) | Dielectric strength of insulation (AC500V,2mA,1S) | Insulation Resistance DC500(MΩ) | Noise dB(A) |
| 12 | 1/22.15 | ≤0.15 | 320±30 | ≤1.7 | ≥245 | No breakdown flying Fox | ≥10 | ≤50 |
Mechanical Dimension: mm
