15BY45-311G PM Stepper Motor
Product Introduction
- Offers a 9° step angle and a 1:50 reduction ratio for precise control.
- Maintains high reliability with AC 500V insulation and minimal noise under 500Hz operation.
Product Application
- Car head-up display (HUD)
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Step Angle | Driving Mode | Excitation Mode | Voltage (VDC） |
Reduction Ratio | Resistance Soil 7%Ω/ Phase (25℃) |
Pull-in Frequeny（Hz） | Pull-out Frequency（Hz） | Pull out Torque (mN•m) 500Hz |
★ Dielectric Strength of Insulation AC (500V, 1mA, 1s) |
★ Insulation Resistance (DC500V) (MQ) |
Noise dB(A) 500Hz |
| 9° /50 | bipolar | 1-2 phase | 12 | 1:50 | 120 | ≥ 700 | ≥ 1200 | ≥ 34.3 | No breakdown or flare | ≥ 100 | No sound when running |
Mechanical Dimensions: mm
