10BY25T PM Stepper Motor
Product Introduction
- Stepper motor 10BY25T
- Bipolar motor with 18° step angle, 5V voltage, Ø2.0 lead screw, 0.4mm lead pitch.、
- Offers 35Ω resistance, 6.0 holding torque, maximum starting frequency 1000 pps, slew speed 2000 pps.
Product Application
Digital camera, security monitoring
- Warm Reminder:
- The following product parameters are standard products, our company can do product design, development and production according to the special needs of customers. For more information, please contact [email protected]
Product Parameters
| Model | Step Angle |
Voltage (V) |
Resistance (Ω) |
Phase | Drive Mode |
Max. starting Frequency (pps) |
Max. slew Speed (pps) |
Holding Torque |
Lead Screw Major Dia | Lead Screw Lead Pitch |
| 10BY25T-01 | 18° | 5.0 | 55 | 2-2 | Bipolar | 800 | 1200 | 6.0 | Ø2.0 | 0.4 |
| 10BY25T-02 | 18° | 5.0 | 35 | 2-2 | Bipolar | 800 | 1200 | 6.0 | Ø2.0 | 0.4 |
| Model | Step Angle |
Voltage (V) |
Resistance (Ω) |
Phase | Drive Mode |
Max. starting Frequency (pps) |
Max. slew Speed (pps) |
Holding Torque |
Pinion Module |
Pinion PCD |
Pinion Z |
| 10BY25-01 | 18° | 5.0 | 14 | 2-2 | Bipolar | 900 | 1500 | 16 | – | – | – |
| 10BY25-02 | 18° | 5.0 | 22 | 2-2 | Bipolar | 1250 | 2000 | 15 | 0.25 | Ø3.25 | 13 |
| 10BY25-03 | 18° | 5.0 | 20 | 2-2 | Bipolar | 1000 | 2000 | 15 | 0.25 | Ø3.25 | 13 |
| 10BY25-04 | 18° | 5.0 | 22 | 2-2 | Bipolar | 1000 | 2000 | 20 | 0.25 | Ø3.25 | 13 |
Mechanical Dimensions: mm
